Olympus OTV-S400 VISERA 4K UHD Camera Control Unit
The Core of Full 4K Image Reproduction.
Overview
Olympus OTV-S400 VISERA 4K UHD Camera Control Unit
The Core of Full 4K Image Reproduction.
4K High-Quality Image Processing
· Wide color gamut
· 16-axial color-phase adjustment (more precise color setting based on surgeon’s preference)
· Improved AE (automatic exposure) function
Improved Operability
· Touch panel enables adjustments during procedure
· Easy registrations and loading of user presets
Specifications
Power Supply | Rated voltage | 220–240 V AC; within ±10% | |
Rated frequency | 50/60 Hz; within ±1 Hz | ||
Rated input | 350 VA | ||
Size | Dimensions (maximum) | 390 (W) × 160 (H) × 506 (D) mm | |
Weight | 13.5 kg | ||
Observation | Signal system | Corresponds to the 4K and HD | |
Signal output (resolution) | 4096 × 2160, 3840 × 2160, or 1920 × 1080 can be selected | ||
Signal output (transmission method) | 3G-SDI or HD-SDI can be selected | ||
White balance adjustment | Available | ||
Standard color chart output | The “Color bar” screen can be displayed | ||
Color tone adjustment | Red adjustment | ±8 steps | |
Blue adjustment | ±8 steps | ||
Chroma adjustment | ±8 steps | ||
Automatic gain control (AGC) | The image can be electrically amplified when the light is inadequate due to the distal end of the endoscope being too far from the object | ||
Contrast | Normal | Normal image | |
High | Darkens the dark part and brightens the bright part compared to normal | ||
Low | Brightens the dark part and darkens the bright part compared to normal | ||
Iris Are | Auto | The exposure area is set automatically to obtain optimum brightness for the subject | |
Center | Center-weighted measuring | ||
Image enhancement settings | Fine patterns or edges in the endoscopic images can be enhanced electrically to increase the image sharpness Either the structural enhancement or edge enhancement can be selected according to the user setup | ||
Structural Enhancement | Enhancement of contrast of the fine patterns in the image | ||
Edge enhancement | Enhancement of edges of the endoscopic image | ||
NBI observation | This observation uses the narrow band observation light | ||
Endoscope’s remote switches function | The functions of the remote switches on the endoscope can be set in the user presets | ||
Documentation | Displaying the record state | The recording state of the video recorder can be displayed on the monitor | |
Displaying the image information | The following data can be displayed on the monitor: · Zoom ratio / One-touch auto focus / Observation mode / NBI observation mode | ||
Memory backup | User presets | Up to 10 user presets can be registered | |
Memorization of selected settings | The following settings are held in memory even after the video system center is turned OFF: · System settings / Color tone / Color mode / Contrast / Enhancement / White balance | ||
Classification (electromedical equipment) | Type of protection against electric shock | Class I | |
Degree of protection against electric shock of applied part | TYPE BF applied part | ||
Degree of protection against explosion | The video system center should be kept away from flammable gases | ||
