Miniature Nephroscope
- wolf
- Germany
Overview
Miniature Nephroscope
15 / 18 Fr. by Lahme
•First Mini Nephroscope specially developed for Mini-PCNL: Trust the Original
•For large lower calix stones as an alternative to ESWL
•Also suitable for children and teenagers
•Stainless steel dilators for time-saving "one-step" dilatation
•Automatic locking mechanism between sheath and telescope
•Fast and safe introduction of auxiliary instruments due to automatic seal on working channel
•Smallest possible sheath size with robust construction due to the use of titanium and stainless steel
Specifications
PANOVIEW operating endoscope, viewing direction12°, outer ø 12 Fr., WL 225 mm,
with laterally offset eyepiece, 6 Fr. working channel,
automatic valve with seal membrane ...................................................................... 8968.421
also:
Sterile universal sealing valve, pack of 5 ................................................................... 4712348
Continuous irrigation sheath, round, WL 205 mm,
with rotatable irrigation ring, distal tip straight, automatic locking mechanism
15 Fr. .................................................................................................................. 8968.001
18 Fr. .................................................................................................................. 8968.011
Obturator, hollow
for sheath 8968.001 ............................................................................................. 8968.101
for sheath 8968.011 ............................................................................................. 8968.111
Amplatz sheath,
18 Fr., WL 150 mm.............................................................................................. 8968.041
Dilator, WL 320 mm, for "one-step" dilatation, stainless steel
12 Fr., suitable for 15 Fr. sheath ............................................................................. 8968.012
15 Fr., suitable for 18 Fr. sheath ............................................................................. 8968.015
Stone grasping forceps, ø 2.0 mm, WL 365 mm,
with overload protection and mouse tooth geometry................................................... 8968.601
Three-pronged stone grasper, ø 2.0 mm, WL 365 mm ............................................ 8968.671
also:
Spare stone grasper, three-pronged ......................................................................... 8968.675
Ultrasound sonotrode,
ø 1.9 mm, WL 344 mm ........................................................................................ 8962.519
Grasping forceps "HySafe",
with alligator jaws, 6 Fr., WL 410 mm .................................................................. 8968.6802
Lithoclast probe,
ø 2.0 mm, WL 425 mm ........................................................................................ 8742.004
